Stetsom STM1206 Mixer Automotive with Frequency from 1HZ ~ 75KHz with 6 Input Channels 4 Equalization Bands Per Channel and 2 Output Channels Main & Auxiliary

With this mixing console, you can play, experiment, and create outstanding sounds.

• Frequency Response (-3dB): 1Hz ~ 75KHz

• Total Harmonic Distortion (T.H.D.): <0.01%

• Signal-to-Noise Ratio (SNR): 110dB

Channel 1 and 2 Input Sensitivity:

• Mic (XLR): Min 480mV ~ Max 7mV

• Line (1/4" Jack): Min 1.8V ~ Max 26mV

Channel 3 to 6 Input Sensitivity:

• Line (1/4" Jack / RCA): Min 1.9V ~ Max 45mV

4-Band Equalizer per Channel:

• High: ±15dB (12KHz)

• Mid High: ±15dB (3.5KHz)

• Mid Low: ±15dB (500Hz)

• Low: ±15dB (80Hz)

Channel 1 and 2 Input Impedance:

• Mic (XLR): Unbalanced 4KΩ / Balanced 8KΩ

• Line (1/4" Jack): Unbalanced 8.5KΩ / Balanced 17KΩ

Channel 3 to 6 Input Impedance:

• Line (RCA): Unbalanced 85KΩ

• Line (1/4" Jack): Unbalanced 95KΩ

Output Impedance:

• Main Out (1/4" Jack / RCA): 47Ω

• Aux Out (1/4" Jack): 47Ω

Maximum Output Level:

• Main Out (1/4" Jack / RCA): 16 dBu / 4.9Vac

• Aux Out (1/4" Jack): 16 dBu / 4.9Vac

Power Supply (POWER Connector): 9V ~ 16V DC
Maximum Power Consumption: 350 mA
Remote Input (REM Connector): 9V ~ 16V DC
Remote Output (REM Connector): 250 mA

Dimensions (H x W x D): 46.5 x 196.5 x 199.5 mm
Weight: 930 g
