Beyma
Beyma - 10MNd - 10" Low & Mid Frequency - Car Audio
Beyma - 10MNd - 10" Low & Mid Frequency - Car Audio
Regular price
$398.00 USD
Regular price
$398.00 USD
Sale price
$398.00 USD
Quantity
Couldn't load pickup availability
| Specifications | |
| Nominal Basket Diameter | 10" |
| Impedance | 4 ohms |
| AES Power Rating | 250 Watts |
| Program Power | 500 Watts |
| Frequency Response | 100Hz - 8kHz |
| Sensitivity (1W/1m) | 101dB |
| Voice Coil Diameter | 2.5" / 62.4mm |
| Recom. Enclosure Volume | .7-2.6 ft3 / 20-70 Liters |
| Voice Coil Length | 10 mm |
| Air Gap Height | 10 mm |
| Mounting Information | |
| Overall Diameter | 10.12" / 257mm |
| Bolt Circle Diameter | 9.61" / 244mm |
| Baffle Cutout Diameter- | |
| - Front Mount | 9.33" / 237mm |
| - Rear Mount | 9.25" / 235mm |
| No. Of Mounting Holes | 8 |
| Volume Displaced By Driver | 0.07 ft3 / 2 Liters |
| Overall Depth | 4.74" / 120.4mm |
| Net Weight | 6.5 lb. / 2.95 kg. |
| Shipping Weight | 7.36 lb. / 3.34 kg. |
| Materials | |
| Basket | Cast Aluminum |
| Cone | High Stiff Paper |
| Surround | Treated Cloth |
| Surround Shape | Triple Roll |
| Voice Coil | Copper |
| Metal Parts | Anti-Corrosion Coated |
| Magnet | Neodymium |
| Thiele-Small Parameters | |
| Resonant Frequency (fs) | 66 Hz |
| Impedance (Re) | 2.8 ohms |
| Coil Inductance (Le) | .5 mH |
| Mechanical Q (Qms) | 14.35 |
| Electrical Factor(Qes) | .36 |
| Total Q (Qts) | .35 |
| Comp. Equivalent Vol. (Vas) | 1.21 ft3 / 34.28 Liters |
| Voice Coil Overhang (Xmax) | 2.8mm |
| Effective Surface Area (Sd) | .0350 m2 |
| Moving Mass (Mms) | 33 Grams |
| Reference Efficiency | 2.69% |
| BL Factor | 10.4N/A |
| Displacement Volume (Vd) | 227 cm3 |
