Black Sheep Audio | 10NEOSQL | 10" High-Performance SPL Subwoofer 🔊
Pure Violence. Industrial Strength. 🏴☠️
The 10NEOSQL is where raw power meets calculated engineering. Designed for those who refuse to settle for "off-the-shelf" performance, this 10-inch beast is built to anchor high-output systems that demand both depth and extreme pressure. With a massive 1500W RMS rating, the 10SPL isn't just a speaker—it’s a declaration of war against the quiet. 🦾🔥
Featuring a specialized Neodymium motor and a heavy-duty chassis, this driver is engineered for maximum thermal stability and relentless excursion. Whether you're chasing a world record or just want a daily that rattles the block, the 10SPL delivers the low-end authority you've been searching for. ⚡🤘
The Heavy Artillery: 💣
Neo-Powered Force: 🧲 Utilizing high-grade Neodymium for a motor structure that provides insane flux density without the unnecessary bulk.
1500W RMS / 3000W Program: ⚡ Massive power handling designed to stay cool under the pressure of continuous high-output runs.
3" (75mm) Voice Coil: 💎 A high-temp CCAW 4-layer coil with a massive 60mm winding depth for extreme linear travel.
Low-End Dominance: 📉 Tuned with an $F_s$ of 43.57Hz, it hits those deep, visceral notes that you feel in your chest.
Carbon Fiber Flex: 🧬 U-shaped carbon fiber high-foam surround paired with a high-mass cone for minimal distortion at peak volume.
Technical Specifications 📊
| Feature | Performance Spec |
| Power Handling | 1500W AES / 3000W Program ⚡ |
| Nominal Impedance | $4\Omega / 4\Omega$ Dual Voice Coil ⚡ |
| Sensitivity (1w/1m) | 85dB 📈 |
| Frequency Range | 43Hz – 500Hz 🔊 |
| Voice Coil | 75mm (3") CCAW 4-Layer 💎 |
| Magnet Material | Neodymium (Neo) 🧲 |
| Net Weight | 9.1KG (20.0 lbs) 🦾 |
The "Nerd" Stats (T/S Parameters) 🤓
F_S$ (Resonance): 43.57 Hz
Q_{TS}$ (Total Factor): 0.90
V_{AS}$ (Air Load): 8.35 L
M_{MS}$ (Moving Mass): 223.10 g
BL$ Factor: 10.63
Mounting & Build Specs 📐
Overall Diameter: 269.5mm (10.6")
Baffle Cutout: 235.3mm (9.2")
Mounting Depth: 230mm (9.0")
Surround Design: U-Shape Carbon Fiber High-Foam 🧬
Sold individually
1 year warranty
The Verdict: 💀
The 10NEOSQL is the ultimate weapon for custom enclosures where compromise isn't an option. For maximum impact, we recommend a 1.5" thick birch baffle to keep the box flex at zero while this monster does its work. Rule the lows. 🔊🏴☠️
